Vertical Electrophoresis
Vertical Electrophoresis
Molecular biology and biochemical research studies are important in terms of precision and
reliability. Being one of the best Vertical Electrophoresis Manufacturers in Chennai, we
are involved in the business of supplying quality electrophoresis systems that are used to
reliably separate nucleic acids and proteins. The designed vertical electrophoresis units are
superior in performance, durability, and ease of use, thus making them a necessity in research
laboratories, teaching institutions, and industrial testing centers.
Vertical electrophoresis is popularly applied in labs to decompose DNA, RNA, and proteins
on the basis of their size and charge on a gel platform. We have created systems that provide
consistent performance and are safe and convenient for the researchers.
Major Features and Specifications
● Gel Size Compatibility: Accepts standard gels (mini, midi, or custom size)
● Voltage Range: The voltage can be adjusted to 300 V as the maximum voltage to
achieve maximum separation.
● Content: High-quality acrylic or polycarbonate tanks to ensure durable use.
● Electrode System: Platinum or carbon electrodes to maintain consistency in
conductivity.
● Buffer Capacity: This is to accommodate enough buffer to allow a uniform electric
field.
● Safety Features: Leak-proof design, overcurrent protection, and insulated housing.
● Temperature Control (optional): Cooling system for sensitive protein samples.
● Convenient Technology: Simple assembly, loading, and gel removal.
Uses of Vertical Electrophoresis
● Protein analysis and purification.
● Genetic separation of DNA and RNA.
● Gene expression and molecular cloning research.
● Bio-tech and pharmaceutical research.
● Laboratory experiments in education and academia.
Why Choose Us?
Being reputed Vertical Electrophoresis Manufacturers in Chennai, we integrate
innovativeness, accuracy, and standardization of quality assurance to provide international
standard systems. Our instruments are reproducible, stable, and safe for the researchers and
educators and provide reliable results in science.
We are also offering technical assistance, spare parts, and system working advice, hence
becoming a partner of choice to the laboratories in India that would want to have reliable
electrophoresis solutions.
Specification
- Dimensions: 13cm(L) x 16cm(B) x 17cm(H)
- No. Of Samples: 7
- Buffer Volume: 250ml (including upper and lower tanks)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 8 x 7cm gel (2 Set)
- 7-well polished Teflon comb with thickness of 0.5mm,1mm and 1.5mm (1No. each)
- Teflon Spacer with thickness of 0.5mm,1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (1 Nos) and Screws (3 Nos)
- Lid & Power cord (1 No. each), Levelling Bubble Fixed
Specification
- Dimensions: 13cm(L) x 21cm(B) x 19cm(H)
- No. Of Samples: 14
- Buffer Volume: 500ml (including upper and lower tanks)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 8 x 7cm gel (2 Set)
- 7-well polished Teflon comb with thickness of 0.5mm,1mm and 1.5mm (2Nos. each)
- Teflon Spacer with thickness of 0.5mm,1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (2 Set) and Screws (3 Nos)
- Lid & Power cord (1 No. each)
Specification
- Dimensions: 21cm(L) x 22cm(B) x 17cm(H)
- No. Of Samples: 13
- Buffer Volume: 500ml (including upper and lower tanks)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 16 x 14cm gel (2 Set)
- 13-well polished Teflon comb with thickness of 0.5mm,1mm and 1.5mm (2Nos. each)
- Teflon Spacer with thickness of 0.5mm,1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (1 Nos) and Screws (3 Nos)
- Lid & Power cord (1 No. each), Levelling Bubble Fixed
Specification
- Dimensions: 23cm(L) x 27cm(B) x 19cm(H)
- No. Of Samples: 26
- Buffer Volume: 600ml (including upper and lower tanks)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 16 x 14cm gel (2 Set)
- 13-well polished Teflon comb with thickness of 0.5mm,1mm (2Nos. each)
- Teflon Spacer with thickness of 0.5mm,1mm (2 Nos. each)
- Clamps and Screws (4 Set) ,Lid & Power cord (1 No. each)
Specification
- Dimensions: 21cm(L) x 30cm(B) x 17cm(H)
- No. Of Samples: 20
- Buffer Volume: 600ml (including upper and lower tanks)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 16 x 20cm gel (2 Set)
- 20-well polished Teflon comb with thickness of 0.5mm,1mm and 1.5mm (2Nos. each)
- Teflon Spacer with thickness of 0.5mm,1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (1 Nos) and Screws (3 Nos)
- Lid & Power cord (1 No. each), Levelling Bubble Fixed
Specification
- Dimensions: 23cm(L) x 32cm(B) x 19cm(H)
- No. Of Samples: 40
- Buffer Volume: 800ml (including upper and lower tanks)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 16 x 20cm gel (2 Set)
- 20-well polished Teflon comb with thickness of 0.5mm,1mm (2Nos. each)
- Teflon Spacer with thickness of 0.5mm,1mm (4 Nos. each)
- Clamps and Screws (1 Nos) and Screws (3 Nos)
- Lid & Power cord (1 No. each)
Specification
- Dimensions: 27cm(L) x 55cm(B) x 20cm(H)
- No. Of Samples: 100
- Buffer Volume: 500 (Upper tank) +1300ml (Lower Tank)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 45 x 22cm gel (2 Set)
- 100-well polished Teflon comb with thickness of 1mm (2Nos. each)
- Teflon Spacer with thickness of 1mm (4 Nos. each)
- Metal Clips (6 Nos), Levelling Screws (1 Pk)
- Lid & Power cord (1 No. each), Levelling Bubble (1 No)
- Aluminium Plate for Heat Exchanger
Specification
- Dimensions: 27cm(L) x 55cm(B) x 25cm(H)
- No. Of Samples: 200
- Buffer Volume: 600ml (Upper tank)+1400ml (Lower Tank)
- Basic unit with Platinum Electrode
- Glass Plate notched & rectangular to run 45 x 22cm gel (2 Set)
- 100-well polished Teflon comb with thickness of 1mm (4 Nos. each)
- Teflon Spacer with thickness of 1mm (6 Nos. each)
- Metal Clips (6 Nos), Levelling Screws (1 Pk)
- Lid & Power cord (1 No. each), Levelling Bubble (1 No)
- Aluminium Plate for Heat Exchanger
Specification
- Dimensions: 12cm(L) x 22cm(B) x 17cm(H)
- No. Of Samples: 10
- Gel Size 10 X 10 Cm
- Buffer Volume: 150ml (Upper tank)+180ml (Lower Tank)
- Basic unit with Platinum Electrode Detachable
- Glass Plate notched & rectangular (2 Set)
- 10-well polished Teflon comb with thickness of 1mm and 1.5mm (1No. each)
- Teflon Spacer with thickness of 1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (1 set) and Levelling Screws (3 Nos)
- Lid & Power cord (1 No. each), Levelling Bubble Fixed
Specification
- Dimensions: 16cm(L) x 22cm(B) x 25cm(H)
- No. Of Samples: 20
- Gel Size 10 X 10 Cm
- Buffer Volume: 150ml (Upper tank)+350ml (Lower Tank)
- Basic unit with Platinum Electrode fixed
- Glass Plate notched & rectangular (2 Set)
- 10-well polished Teflon comb with thickness of 1mm and 1.5mm (2No. each)
- Teflon Spacer with thickness of 1mm & 1.5mm (4 Nos. each)
- Clamps and Screws (2 set)
- Lid & Power cord (1 No. each), Water Circulation
Specification
- Dimensions: 12cm(L) x 23cm(B) x 17cm(H)
- No. Of Samples: 16
- Gel Size 16 X 10 Cm
- Buffer Volume: 250ml (Upper tank)+280ml (Lower Tank)
- Basic unit with Platinum Electrode Detachable
- Glass Plate notched & rectangular (2 Set)
- 16-well polished Teflon comb with thickness of 1mm and 1.5mm (1No. each)
- Teflon Spacer with thickness of 1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (1 set) and Levelling Screws (3 Nos)
- Lid & Power cord (1 No. each), Levelling Bubble Fixed
Specification
- Dimensions: 16cm(L) x 23cm(B) x 25cm(H)
- No. Of Samples: 32
- Gel Size 16 X 10 Cm
- Buffer Volume: 250ml (Upper tank)+350ml (Lower Tank)
- Basic unit with Platinum Electrode fixed
- Glass Plate notched & rectangular (2 Set)
- 16-well polished Teflon comb with thickness of 1mm and 1.5mm (2No. each)
- Teflon Spacer with thickness of 1mm & 1.5mm (4 Nos. each)
- Clamps and Screws (2 set)
- Lid & Power cord (1 No. each), Water Circulation.
Specification
- Dimensions: 12cm(L) x 26cm(B) x 17cm(H)
- No. Of Samples: 20
- Gel Size 20 X 10 Cm
- Buffer Volume: 350ml (Upper tank) +300ml (Lower Tank)
- Basic unit with Platinum Electrode Detachable
- Glass Plate notched & rectangular (2 Set)
- 20-well polished Teflon comb with thickness of 1mm and 1.5mm (1No. each)
- Teflon Spacer with thickness of 1mm & 1.5mm (2 Nos. each)
- Clamps and Screws (1 set) and Levelling Screws (3 Nos)
- Lid & Power cord (1 No. each), Levelling Bubble Fixed
Specification
- Dimensions: 16cm(L) x 26cm(B) x 25cm(H)
- No. Of Samples: 40
- Gel Size 20 X 10 Cm
- Buffer Volume: 400ml (Upper tank)+500ml (Lower Tank)
- Basic unit with Platinum Electrode fixed
- Glass Plate notched & rectangular (2 Set)
- 20-well polished Teflon comb with thickness of 1mm and 1.5mm (2No. each)
- Teflon Spacer with thickness of 1mm & 1.5mm (4 Nos. each)
- Clamps and Screws (2 set)
- Lid & Power cord (1 No. each), Water Circulation.
